The P4H is a 2-in-1 solution visualizer (Document Camera), with a 13-megapixel camera, 4K at 30fps streaming, and 30X digital zoom capability, it allows the teacher to show every detail without any missing, no matter for demonstrating books, or to show any materials. your students can see clear image whether they are in-class or remote, the foldable mechanical arm can be firmly folded into a neat body and stored in the bag, it is very convenient for the teacher to carry the device anywhere for teaching, recording, live streaming or planning of the course. Besides, the P4H has an easily operable control panel to improve teaching efficiency.
With 4K resolution plus 30X digital zoom capability, you can magnify on a specimen or any object and see every detail with amazing clarity.
The P4H equipped with an adjustable height mechanical arm.
It allows you to capture larger A3 documents, books, and present anything you want from any angle.
The P4H is equipped with a fully adjustable mechanical arm,
it can expand and collapse to the perfect angle allow you to see more details with a closer view.
The P4H is UVC/UAC compliant with plug-and-play USB connectivity and features a built-in mic. It supports integration with all popular video conferencing applications such as Zoom, Microsoft Teams, Google Meet, Cisco Webex, and Go To Meeting, so you’re ready to tackle distance learning.
The P4H integrates physical buttons for a more convenient user experience,
it allows you to freeze the video, rotate image, and zoom in/out of the screen during the demonstration.
Use the powerful VisualCam software to enhance your education, this visualizer software provides various tools, split-screen comparison, picture-in-picture recording, and an interactive whiteboard to achieve a more user experience.
|Image sensor||1/3” , 13MP CMOS|
|Max. Shooting Area||440mm x 330mm (17.3"x13")|
|Output Resolution (HDMI mode)||3840x2160 (4K, 16:9)|
1920x1080 (Full HD, 16:9)
1280x720 (HD, 16:9)
1024x768 (XGA, 4:3)
|Frame Rate (USB mode)||4192x3104@10fps (MJPG only for capture A3 area image)|
|Video Compression||MJPG、H.264, YUY2|
|Focus||Auto / Manual|
|Image Rotation||0° / 90° / 180° / 270° / Flip / Mirror|
|Support Power Line Frequency||50/60 Hz|
|Connectivity||USB (Type-C) / HDMI|
|Microphone||Built-in Omnidirectional Microphone|
|Microphone Sensitivity||1kHz(0dB=1V/Pa) Min-45 Nom-42 Max-39 dB|
|Powered By||USB Type-C (5V/900mA)|
|Protocol||UVC / UAC|
|Support Operating System (UVC)||Windows® 10, Windows 8, Windows 7|
macOS® 10.10 or above
|Dimensions||Extended: 347x115x381 mm|
Closed: 242x115x87 mm
|Accessories||Quick Start Guide x1, USB Cable x 1|
